Description 8-inch woven composite, low-frequency transducer 1.25-inch (31.75 mm), ultra-low-mass, silk-dome, high-frequency transducer 120˚(H) x 60˚(V) EBM waveguide for a wide sweet spot Front-firing acoustic port for superior bass-frequency reproduction and optimized, resonance-suppressing internal bracing 140W, Class AB biamplification 35 Hz to 20 kHz frequency response 106 dB SPL (Peak, @ 1 meter) Acoustic Tuning controls: HF (±6 dB, continuously variable); Midrange (±6 dB, continuously variable), and Acoustic Space (flat, -2, -4 dB), plus highpass filter (Off, 80 Hz, 100 Hz) RF interference, output-current limiting, over-temperature, transient, subsonic protection, and amplifier “soft start” feature (eliminates popping on power-up) Internal power supply with IEC connector and power switch with on/off LED Balanced XLR and ¼-inch inputs and unbalanced RCA inputs1
